Description
* The climbing route is predetermined and has a second level of difficulty
Technical Specification:
Type of structure
Kite Sky Fun Wall comes with our standard steel structure which needs to be anchored in the floor and on the top of the frame. Structure for outdoor locations comes hot dip galvanized which ensures its durability and resistance from weather conditions all around the world
Anchoring
You need to anchor two base steel plates, each with four anchors at the bottom, and also secure two attachment points at the top. The top attachment points may vary depending on the installation space to properly support your Kite Sky. The structure should be anchored in solid concrete slab with a minimum thickness of 15cm. To make sure that your floor can support the Kite Sky please find attached the static calculations of the loads Walltopia Standard Loads File in the downloadable section and always consult with your engineer or a qualified professional.
Placement
Kite Sky should be placed away from hard objects such as building columns, railings, furniture or other. The Safety zone dimensions are defined in the product pictures. This is the zone that is mandatory to keep clear of any obstructions
Flooring
We strongly recommend installing safety flooring in the safety zone around every climbing wall. You can purchase 15cm thick Rope Wall Mat with grey carpet finish or One More Life Safety Flooring from Walltopia or install other type of shock absorbent flooring.
Additional products
This product can not be used without an autobelay system!
Our Fun Walls Structure are compatible with Tru Blue Auto Belay by Headrush and Perfect Descend Auto Belay Device
Do not forget to check our safety accessories here. Safety Gates ease operation and mitigates the risk of unsecured climbing. Auto Belay webbing is attached to them when no one is climbing. Auto Belay webbing is attached to them when no one is climbing.
Choose to install our Smart Gate and reduce the risk of incidents to minimum. We also recommend our Self Belay system that not only contributes to climbing safety but also helps operations by reducing the number of required staff members – participants as young as 5 years of age can use the device on their own, without supervision!
Shipping options
This product will be shipped in parts and requires assembly upon delivery. All components, including the steel structure, are designed for easy assembly. Detailed instructions are provided to ensure the final product is safe to operate ad has excellent look and finish.
Machinery needed for assembly
List of tools: Impact driver, Drill driver, Angle grinder, Impact gun – sockets 17/ 19, Jigsaw, Manual wrenches – 13 / 17 / 19 / 24, Pillars, Measure tapes
Machinery: Scissor lift capable to lift 260 kg up to 8 meters, Forklift 2T – for the unloading, Pallet jack
